Technical Service Manual 39
ISA Series Power Amplifiers
6.4 ISA450 parts and assemblies
ISA450 Power Amplifier
120V: QSC part # FG-004500-00
230V: QSC part # FG-004500-02
220V Korea: QSC part # FG-004500-03
240V UK: QSC part # FG-004500-04
QSC part # Description Qty. Reference Comments
CH-000155-GP TOP COVER ISA 1
CO-000228-GP EURO 3 PIN CONNECTOR, GRN 2
LB-000438-GP LABEL, WARNING, RAIN & MOISTURE 1
PL-000156-GP RUBBER FEET 4
PL-000164-GP AC CORD PROTECTOR 1
PM-000042-GP SHIPPING CARTON, BOX, ISA 3RU (NEW QSC) 1
PM-000043-GP CARTON, INSERT 2
PM-000048-GP POLYBAG MANUAL 1
PM-000049-GP BAG, PLASTIC, 4" X 6" 1
PM-000050-GP BAG, POLY, RMX, 430 X 505 X 360MM 1
PM-000063-GP POLYBAG 1
SC-040008-GP P/P, M4, 10MM, BLK, TRIANGULAR TIP 16 ALT. P/N: SC-040002-GP
TD-000093-00 OWNERS MANUAL, ISA, 1
TD-000900-AX WARRANTY CARD, GENERIC, 1 120V only
TS-000004-WR 3 YEARS WARRANTY 3
WC-000181-GP AC CORD 15A ISA 1 100V and 120V only
WC-000213-GP AC CORD 1 230V only
WC-000273-GP AC CORD 240V UK, FUSE 13A 1 240V UK only
WP-004500-00 ISA 450 CHASSIS ASSY (120V) 1 Before May 2006 100V and 120V only
WP-004500-02 ISA 450 CHASSIS ASSY (230V) 1 Before May 2006 230V only
WP-004500-03 ISA 450 CHAS ASSY (220V 60HZ) 1 Before May 2006 220V Korea only
WP-004503-00 ISA 450 CHASSIS ASSY (120V) 1 Beginning May 2006 100V and 120V only
WP-004503-02 ISA 450 CHASSIS ASSY (230V) 1 Beginning May 2006 230V only
WP-004503-03 ISA 450 CHAS ASSY (220V 60HZ) 1 Beginning May 2006 220V Korea only
Chassis Assembly ISA450 (beginning June 2006)
120V: QSC part # WP-004503-00
230V: QSC part # WP-004503-02
220V Korea: QSC part # WP-004503-03
QSC Part # Description Qty. Reference Comments
CH-000153-GP CHASSIS FAB ISA 1
CH-000166-GP RACK EAR ISA 2
CH-000173-GP COVER, XFMR, STEEL, LARGE 1
CH-000178-GP PROTECT COVER 1
CO-000211-GP AC INLET 250V 15A 1
CO-000218-GP 6 POLE SPEAKER TERMINAL 1
LB-000355-GP LABEL, GROUND 1
LB-000410-GP LABEL “UL LISTED” 1
LB-000448-GP LABEL, REAR, ISA (NEW) 1
MS-000122-GP DC FAN, 24V 119X119X38MM 1
MS-000124-GP FUSE 12A 250V 6.3 X 32MM 2
MS-000131-GP FAN GUARD, BLACK 1
NW-030002-GP I/T WASHER M3 X 0.5 X 6.4 WZ 1
NW-040001-GP NUT KEPS M4 4
PL-000149-GP KNOB, VR 2
PL-000157-GP XFMR RUBBER PAD (LARGE) 2
SC-000019-GP BOLT, M8 X 80MM, , , WHT ZINC, 1
SC-030001-GP BH M3 X 10MM BZ CRD, B-TITE 4
SC-030002-GP M3 B-TITE FLAT-CS 2
SC-030004-GP M3 X 8 BLK MACHINE 16
SC-030005-GP M3 X 12MM (BLK/ZINC) 8
SC-030011-GP M3 X 8 MM NICKEL 2
