QSC ISA280 - Main PCB Assembly ISA800 T; Technical Service Manual; ISA Series Power Amplifiers

Technical Service Manual 59
ISA Series Power Amplifiers
SW-000094-GP CIRCUIT BREAKER 8A 1 230V only
WC-000169-GP CONN ASSY 2PIN ISA 2
WC-000171-GP CONN ASSY 3-PIN 1
WC-000173-GP CONN ASSY 4P P2.5 L=200 AWG26 2
WC-000174-GP CONN ASSY 6-PIN ISA 280 1
WC-000175-GP CONN ASSY 8P P2.5 L=460 AWG26 1
WC-000177-GP UL1015 #14 2P GRN L=100 1
WC-000179-GP UL1015 #16 3P BRN L=360 2
WC-000180-GP UL1015 #16 2P OFFWHITE 2
WC-000182-GP CONN ASSY 13P P2.0 L=240 1
WC-000192-GP UL 2547 3-PIN P2.5 L=250 2
WC-000198-GP GROUND WIRE 1
WC-000199-GP UL 1015 AWG#14 BROWN 1
WC-000211-GP WIRE ASSY, FAN GROUND 1
WP-000068-00 SRV - XFMR MNTG ASSY ISA SERIES 1
WP-000069-00 SRV - XFMR MNTG ASSY ISA300/500/800T 2
WP-000806-00 MAIN PCB ASSY, ISA 800T 1
WP-007502-00 PCB ASSY, AC/INPUT ISA750(120V) 1 120V only
WP-007502-02 PCB ASSY, AC/INPUT, ISA750, 230V, 1 230V only
XF-000192-GP PWR XFMR ISA800T/750 1
XF-000226-GP LINE XFMR ISA 800T 2
Main PCB Assembly ISA800T
QSC part # WP-000806-00
QSC Part # Description Qty. Reference Comments
CA-027003-GP CTC 200V 27PF 5% 1206 2 C111, C211
CA-047005-GP CC 50V 47PF 5% 0805 6 C170, C176, C177, C270, C276, C277
CA-056001-GP CC 50V 56PF 10% 0805 2 C110, C210
CA-110004-GP CC 50V 100PF 10% 0805 2 C9, C132
CA-110005-GP CC 50V 100PF 5% 0805 1.2 1 C130
CA-118000-GP CC 50V 180PF 5% 0805 4 C101, C103, C201, C203
CA-210012-GP CM 100V .001UF 5% RL 5X 2 C131, C231
CA-215004-GP CM 250V .0015UF 5% RL 2 C114, C214
CA-222007-GP 50V .0022UF 10% 1206 4 C115, C117, C215, C217
CA-233004-GP CM 50V .0033UF 5% RL 4 C172, C179, C272, C279
CA-310009-GP CC 50V .01UF 20% 0805 3 C5, C181, C281
CA-322006-GP CM 50V .022UF 5% RL 4 C116, C119, C216, C219
CA-322007-GP CC 50V .022UF 10% 0805 2 C133, C233
CA-368004-GP 0.068UF 5% 250V FILM DIPPED 4 C124, C126, C224, C226
CA-410014-GP 0.1UF 10% 50V CER X7R 0805 2 C11, C104
CA-410015-GP CM 50V .1UF 5% RL 6 C107–C109, C207–C209
CA-410016-GP CC 50V .1UF 10% 1206 2 C178, C278
CA-410018-GP CM 250V .1UF 5% RL 4 C174, C175, C274, C275
CA-547008-GP 4.7UF 20% 250V ELECTRO RAD 1 C7
CA-610009-GP CE 35V 10UF 20% RL 5 X 11 2 C171, C271
CA-622007-GP CE 25NP 22UF 20% RL 5X11 2 C129, C229
CA-647000-GP 47UF 16V 20% ELECTROLYTIC RL 3 C8, C106, C206
CA-710009-GP CE 25V 100UF 20% RL 6 C105, C173, C180, C205, C273, C280
CA-710010-GP CE 16NP 100UF 20% RL 8X11 2 C125, C225
CA-722006-GP CE 25V 220UF 20% RL 5 C13, C112, C113, C212, C213
CA-912001-GP 12000UF, 20 PCNT, 63V, RL, , 8 C120–C123, C220–C223
CH-000163-GP HEATSINK ISA 750 3 SP 1
CH-000165-GP PCB HOLDER ISA GPE 1
CH-000168-GP VR BRACKET ISA 2
CH-000171-GP BRACKET, RT ANGLE HD15 2
CH-000172-GP CLAMP TRANSISTOR 8
CO-000213-GP CONN 2 PIN STRAIGHT WAFER 2 J207, J425
CO-000214-GP CONN 3 PIN STRAIGHT WAFER 5 J108, J208, J257, J401, J402
CO-000215-GP CONN 4 PIN STRAIGHT WAFER 6 J105, J106, J205, J206, J422, J423
Chassis Assembly ISA800T continued
QSC Part # Description Qty. Reference Comments
