Supported 1D barcodes
Code 39
Interleaved 2 of 5
Code 128, horizontal printed
Note: A vertical printed "Code 128" is not supported. It may work but it is not recommended
because it is very sensitive to speed variations.
- Minimum line thickness of a bar: 0,20 mm (0.008")
- Maximum line thickness of a bar (smallest element): 0,50 mm (0.02")
- The thickness ratio of thick bars versus thin bars: 2.2
- Preferred print quality: 600dpi
- Minimum width of the barcode: 5 mm (0.2")
- Maximum qty. of characters: 109
- Quiet zone (free white space area): 5 mm (0.2").
