Specifications11
System Specifications
DS-77iQ, FPi 4800, FD6308, TSI-5S, C777iQModel
Folder and inserter system for medium office use.Type
3800 inserts per hour, depending on application.Theoretical max. speed
Standby: 0.33 WPower consumption
Idle: 15.5 W
Run mode: 160 W
100V: +6% / -10%Voltage tolerance
115V: +6% / -10%
230V: +10% / -10%
100/115 Vac: T 5.0 A, 125 V.Fuse
Time lag, 5.0 Amps. rated current, 125 V.
230 Vac: T 2,5 A H, 250 V.
Time lag, 2.5 Amps. rated current, high breaking
capacity, 250 V.
RED (Radio Equipment Directive) 2014/53/EUApprovals
FCC Certificate conform 47CFR, part 15
CB Certificate conform IEC 62368-1
UL Listed I.T.E. (Information Technology Equip-
ment), conform UL-IEC 62368-1, file E153801
Conform NEN-EN-IEC 62368-1 and derivatives.
<66 dBA (according to ISO 11202)Noise Level
<67 dBA With High Capacity Vertical Stacker
10°C - 40°C (50°F-104°F)Operating temperature
30%-80%Humidity
141
| Page 141 | Jul-11-2022 07:45 | Specifications
