GFEDCBA
60 g/m2
84 mm130 mm10 mm32 mm90 mm160 mm
Minimum
size
3.3”5.1”0.4”1.25”3.5”6.3”
2.5 mmB-6A-12*35 mmB-32162 mm248 mm
Maximum
size
0.1”B-0.2A-0.47**1.38”B-1.256.38”9.7”
* Booklets up to approximately 1 mm (0.04 inch) thickness, depending on stiffness
** When insert is more than 1 mm (0.04 inch): A-15 mm / A-0.6 inch
Envelope quality
80 g/m² (20 lb bond)Minimum
120 g/m² (30 lb bond)Maximum
Remarks:
• The specification of the paper handling equipment is often wider than that of the
envelopes and documents handled. The condition of material handled will limit the
specified environmental conditions.
• We recommend that materials to be handled are stored at a temperature of 20°C
(68°F) with a relative humidity factor of 50%. If difference in temperature occurs
between store room and mailing area, the material has to be stored near the machine
at least 24 hours before use.
144
| Page 144 | Jul-11-2022 07:45 | Specifications
