Quantum DXi6900

Chapter 9: Configuration
Notifications
Quantum DXi6900 User’s Guide 297
Figure184:Add Trap Destination Page
2. Enter information about the destination:
IPAddress Enter the IP address of the system that will receive the traps generated by the DXi6900.
AdditionalInformation
l When entering IP addresses, never use an address that is in a reserved IP address
range. To see a list of reserved IP address ranges, click the quick tip icon [?]
located near the IP address field.
l To use hostname format, you must specify at least one DNS IP address on the
Network page (see Network on page 305).
Name Enter the name of the destination.
3. Select one or more traps to send to the destination:
Failure Sends failure traps.
Warning Sends warning traps.
Informational Sends informational traps.
Available Sends a trap when the system transitions from an unavailable to an available state.
Unavailable Sends a trap when the system transitions from an available to an unavailable state.
4. Click Apply.
