Quantum QX Series

Chapter 6: LEDDescriptions
LEDs for 12-, 24-, 48-Drive Systems
QX and QXS Setup Guide 167
DrivemoduleLEDbehavior LFF—12-drive SFF—24-drive
Description State Color Action Color Action
Drive leftover Drive is a leftover Amber On Amber On
Identifying a leftover Amber Blink Amber Blink
Blue
1
On Blue
1
Blink
Drive failed Fault or failure Amber On Green
1
On
Amber On
Fault and remove drive Amber On Green On
Blue On Amber On
Fault and identify drive Amber Blink Green On
Amber On
Fault, identify, and remove drive Amber Blink Green On
Blue On Amber Blink
Blue On
1
This color may or may not illuminate.
Note:If a user interface shows the drive LED is Fault (amber), while the chassis shows it is green, the
fault might be in the midplane or the drive’s midplane connector.
VdiskLEDbehavior LFF—12-drive
1
SFF—24-drive
Description State Color Action Color Action
FTOL On (operating normally) Green Blink Green On
Vdisk activity Vdisk is reconstructing Green Blink Green Blink
Vdisk is initializing Green Blink Green Blink
Vdisk degraded Vdisk is critical/down See note 1 below See note 1 below
Table48:LEDs: Vdisks in LFF and SFF chassis
1
Individual drives will display fault LEDs
