Quantum QX Series User Manual

Chapter 7: Environmental Requirements and Specifications
Physical Requirements
QX and QXS Setup Guide 193
Specifications Rackmount
SFF (2U48):
l Chassis with FRUs (no drives)
1-3
l Chassis with FRUs (including drives)
1-4
12.7 kg (28.0 lb) [chassis]
l 23.1 kg (50.9 lb)
l 34.0 kg (74.9 lb)
High-capacity controller chassis (4U56)
l Chassis with FRUs (no drives)
1-3
l Chassis with FRUs (including drives)
1-4
14.9 kg (32.8 lb) [chassis]
l 46.3 kg (102.1 lb)
l 87.0 kg (191.7 lb)
1
Weights shown are nominal, and subject to variances.
2
Rail kits add between 2.8 kg (6.2 lb) and 3.4 kg (7.4 lb) to the aggregate chassis weight.
3
Weights may vary due to different power supplies, IOMs, and differing calibrations between scales.
4
Weights may vary due to actual number and type of drives (SAS SSD, enterprise SAS, or midline SAS) and air management
modules installed.
Table 67 below provides information about optional drive chassis that are compatible with QXS Storage
controller chassis.
Specifications Rackmount
2U12 (LFF 3.5" 56-drive chassis)
l Chassis with FRUs (no drives)
1-3
l Chassis with FRUs (including drives)
1-4
8.6 kg (19.0 lb) [chassis]
l 16.2 kg (35.8 lb)
l 22.2 kg (49.0 lb)
2U24 (SFF 2.5" 24-drive chassis)
l Chassis with FRUs (no drives)
1-3
l Chassis with FRUs (including drives)
1-4
8.6 kg (19.0 lb) [chassis]
l 16.1 kg (35.6 lb)
l 25.6 kg (56.6 lb)
2U48 (SFF 2.5" 48-drive chassis):
l Chassis with FRUs (no drives)
1-3
l Chassis with FRUs (including drives)
1-4
12.7 kg (28.0 lb) [chassis]
l 20.3 kg (44.8 lb)
l 31.2 kg (68.8 lb)
High-capacity controller chassis 4U56 (LFF 3.5" 56-drive chassis)
l Chassis with FRUs (no drives)
1-3
l Chassis with FRUs (including drives)
1-4
14.9 kg (32.8 lb) [chassis]
l 45.0 kg (99.1 lb)
l 85.6 kg (188.7 lb)
Table67:2U Rackmount compatible drive expansion chassis weights (ordered separately)
1
Weights shown are nominal, and subject to variances.
2
Rail kits add between 2.8 kg (6.2 lb) and 3.4 kg (7.4 lb) to the aggregate chassis weight.
3
Weights may vary due to different power supplies and differing calibrations between scales.
4Weights may vary due to actual number and type of drives (SAS SSD, enterprise SAS, or midline SAS) and air management
modules installed.
