GV320 User manual
TRACGV320UM001 - 9 -
Table 3. Part List
Name Picture
GV320 Locator 80*49*26 mm
User Cable
Extend Cable (Optional)
GPS Antenna (Optional)
DATA_CABLE_M (Optional)
The GV320 has a 16 PIN interface connector. It contains the connections for power, I/O,
RS232, microphone, speaker, etc. The sequence and definition of the 16PIN connector
are shown in following figure:
2.2. Parts List
2.3. Interface Definition
