Quectel EG91 Series User Manual

LTE Standard Module Series
EG91 Series Hardware Design
EG91_Series_Hardware_Design 90 / 106
7 Mechanical Dimensions
This chapter describes the mechanical dimensions of the module. All dimensions are measured in
millimeter (mm), and the dimensional tolerances are ±0.05 mm unless otherwise specified.
7.1. Mechanical Dimensions of the Module
25±0.15
29±0.15
2.30±0.2
Pin 1
Figure 41: Module Top and Side Dimensions
