LTE Standard Module Series
EG91 Series Hardware Design
EG91_Series_Hardware_Design 94 / 106
For easy maintenance of this module, please keep about 3 mm between the module and other
components on the motherboard.
7.3. Top and Bottom Views of the Module
Figure 45: Top View of the Module
NOTE
