LTE Standard Module Series
EG91 Series Hardware Design
EG91_Series_Hardware_Design 20 / 106
Figure 1: Functional Diagram
1)
GNSS antenna interface is only supported on EG91-NA/-NS/-VX/-EX/-NAX/-NAXD/-AUX.
2.4. Evaluation Board
Quectel provides a complete set of evaluation tools to facilitate the use and testing of EG91 series module.
The evaluation tool kit includes the evaluation board (UMTS<E EVB), USB data cable, earphone,
antenna and other peripherals. For more details, please refer to document [7].
