Figure 46: EG91-E Bottom View of the Module
Figure 47: EG91-EX Bottom View of the Module
These are renderings of the module. For authentic appearance, please refer to the module received from
Quectel.
2. EG91-NA, EG91-NS, EG91-VX, EG91-NAX, EG91-NAXD and EG91-AUX modules bottom view is as
the same as EG95-EX.
NOTES
