M10_HD_V3.0
-
4
9
-
3.9.3. Receiver and speake
r interface c
onfiguration
SPK1P
SPK1N
Differential layout
10pF
10pF
33pF
33pF
33pF
Close to speaker
GND
GND
10pF
ESD
ESD
Module
Figure 28: Speaker interface configuration of AOUT1
SPK1P
SPK1N
Differential layout
Amplifier
circuit
10pF
10pF
33pF
33pF
33pF
Close to speaker
GND
GND
10pF
ESD
ESD
Module
Figure 29: Speaker interface with
amplifier configuration of AOUT1
Texas Instruments TPA6205
A1is recommended for a
suitabl
e differential audio
amplifier. There
are plenty of excellent audio
amplifiers in the m
arket.
49
