Quectel M10

M10 Hardware Design
M10_HD_V3.0 - 70 -
Parameter Description Conditions Min Type Max Unit
DCS1800/PCS1900
2)
423/445 mA
Peak supply
current
(during
transmission
slot)
Maximum power control level
on GSM900.
1.6 1.8 A
1)
Power control level PCL 5
2)
Power control level PCL 0
5.4. Current consumption
The values of current consumption are shown in Table 34.
Table 34: The module current consumption
Condition Current Consumption
Voice Call
GSM850 @power level #5 <300mA,Typical 209mA
@power level #12,Typical 96mA
@power level #19,Typical 73mA
GSM900 @power level #5 <300mA,Typical 208mA
@power level #12,Typical 96mA
@power level #19,Typical 73mA
DCS1800 @power level #0 <250mA,Typical 191mA
@power level #7,Typical 93mA
@power level #15,Typical 70mA
PCS1900 @power level #0 <250mA,Typical 202mA
@power level #7,Typical 95mA
@power level #15,Typical 71mA
GPRS Data
DATA mode, GPRS ( 1 Rx,1 Tx ) CLASS 12
GSM850 @power level #5 <350mA,Typical 199mA
@power level #12,Typical 87mA
@power level #19,Typical 63mA
EGSM 900 @power level #5 <350mA,Typical 200mA
@power level #12,Typical 96mA
@power level #19,Typical 70mA
DCS 1800 @power level #0 <300mA,Typical 184mA
@power level #7,Typical 82mA
@power level #15,Typical 66mA
PCS 1900 @power level #0 <300mA,Typical 192mA
@power level #7,Typical 82mA
