Quectel RG255C-GL User Manual

5G Module Series
RG255C-GL_Mini_PCIe_Hardware_Design 18 / 57
Keep all NC, RESERVED and unused pins unconnected.
2.6. EVB Kit
Quectel supplies an evaluation board (Mini PCIe EVB) with accessories to develop and test the module.
For more details, see documents [2].
52
VCC_3V3
PI
Power supply for the
module
Vmin = 3.0 V
Vnom = 3.3 V
Vmax = 3.6 V
NOTE
