Table 25: Electrostatic Discharge Characteristics (Temperature: 25–30 °C, Humidity: 40 ±5 %)
6.4. Power Consumption
Table 26: Averaged Power Consumption
Tested Interfaces
Contact Discharge
Air Discharge
Unit
VBAT, GND
±5
±10
kV
Antenna Interfaces
±4
±8
kV
Other Interfaces
±0.5
±1
kV
Mode
Condition
Band/Combination
Typ.
Unit
Turn off
Power off
-
TBD
μA
RF Disabled
AT+CFUN=0 (USB 2.0 suspend)
-
TBD
mA
AT+CFUN=4 (USB 2.0 suspend)
-
TBD
mA
Idle mode
SA PF = 64 (USB 2.0 active)
-
TBD
mA
SA PF = 64 (USB 2.0 active)
-
TBD
mA
LTE data
transmission
(GNSS OFF)
LTE LB @ 24 dBm
B5
TBD
mA
LTE MB @ 24 dBm
B1
TBD
mA
LTE HB @ 24 dBm
B7
TBD
mA
LTE HPUE @ 24 dBm
B41
TBD
mA
5G SA data
transmission
(GNSS OFF)
5G NR LB @ 23 dBm
n5
TBD
mA
5G NR MB @ 23 dBm
n1
TBD
mA
5G NR HB @ 23 dBm
n7
TBD
mA
5G NR 5GLM_UHB @ 26 dBm
n78
TBD
mA
5G NR 5GH @ 26 dBm
n79
TBD
mA
