Quectel RG255C-GL User Manual

5G Module Series
RG255C-GL_Mini_PCIe_Hardware_Design 49 / 57
7 Mechanical Information
This chapter mainly describes mechanical dimensions as well as packaging specification of RG255C-GL
Mini PCIe module. All dimensions are measured in millimeter (mm), and the dimensional tolerances are
±0.15 mm unless otherwise specified.
7.1. Mechanical Dimensions
Figure 21: Mechanical Dimensions
The package warpage level of the module refers to the JEITA ED-7306 standard.
NOTE
