3.8. Status Indicators
There are twelve status indication LEDs on the EVB, eight of which are module status indicators and the
other four are Wi-Fi/Bluetooth status indicators. The following two figures show positions of these LED
indicators.
C8
D1201 D1203
D1206
D1208
D1205
D1202
D1204 D1207
Figure 20: Module Status Indicators
RESTORE_KEY
S1201
Used to restore the module
USB_BOOT Switch
S1205
Emergency download control
