Quectel RM520N-GL - Tx Power; GNSS Antenna Interface; General Description; GNSS Frequency

5G Module Series
RM520N-GL_Hardware_Design 60 / 84
5.1.3. Tx Power
The following table shows the RF output power of the module.
Table 31: Cellular Output Power
5.2. GNSS Antenna Interface
5.2.1. General Description
The module includes a fully integrated global navigation satellite system solution (GPS, GLONASS, BDS,
Galileo and QZSS).
The module supports standard NMEA-0183 protocol, and outputs NMEA sentences at 1 Hz data update
rate via USB interface by default.
The GNSS engine is switched off by default. It has to be switched on via AT command.
5.2.2. GNSS Frequency
Table 32: GNSS Frequency
16
For 5G NR TDD bands, the normative reference for this requirement is TS 38.101-1 clause 6.3.1.
Mode
Frequency
Max.
Min.
WCDMA
WCDMA bands
24 dBm +1/-3 dB (Class 3)
< -50 dBm
LTE
LTE bands
23 dBm ±2 dB (Class 3)
< -40 dBm
LTE HPUE bands
(B38/B41/B42/B43)
26 dBm ±2 dB (Class 2)
< -40 dBm
5G NR
5G NR bands
23 dBm ±2 dB (Class 3)
< -40 dBm
16
5G NR HUPE bands
(n38/n40/n41/n77/n78/n79)
26 dBm +2/-3 dB (Class 2)
< -40 dBm
16
Bands
Type
Frequency
Unit
L1
GPS/Galileo/QZSS
1575.42 ±1.023 (L1)
MHz
Galileo
1575.42 ±2.046 (E1)
MHz
