Quectel RM520N-GL - Electrical Characteristics and Reliability; Power Supply Requirements; Power Consumption

5G Module Series
RM520N-GL_Hardware_Design 68 / 84
6 Electrical Characteristics and
Reliability
6.1. Power Supply Requirements
The typical input voltage of the module is 3.7 V, the following table shows the power supply requirements
of the module.
Table 36: Power Supply Requirements
6.2. Power Consumption
Table 37: Averaged Current Consumption
Parameter
Description
Min.
Typ.
Max.
Unit
VCC
Power Supply
3.135
3.7
4.4
V
Voltage Ripple
-
30
100
mV
Mode
Conditions
Band/Combinations
Current
Unit
Power-off
Power off
-
TBD
μA
RF Disabled
AT+CFUN=0 (USB 3.1 suspend)
-
TBD
mA
AT+CFUN=4 (USB 3.1 suspend)
-
TBD
mA
Sleep State
SA FDD PF = 64 (USB 3.1 suspend)
-
TBD
mA
SA TDD PF = 64 (USB 3.1 suspend)
-
TBD
mA
