Quidel Sofia - Power Up

Page 18 of 57
Figure 3
Loading Paper
Load paper into the integrated printer of Sofia (Figure 4).
 Lift black handle to remove paper cover.
 Place paper roll in Sofia with the paper tail coming from under the roll towards the
operator.
 Holding the paper tail towards the operator, replace the paper cover and snap in place.
Figure 4 Roller Bar
Note: The paper does not need to be fed through the roller bar.
Note: If the roller bar disconnects from paper cover, snap into place with gear on the left
(Figure 4).
