Two and four value lines screens
This type of Main screen shows the value of 2 or 4 parameters (see section Inputs menu).
Typical Main screen (2 value lines), fixed speed compressors
Typical Main screen (2 value lines), compressors with frequency converter
Text on figures
(1) Compressor Outlet
(2) Element Outlet (fixed speed compressors)
Flow (compressors with frequency converter)
(3) Load, shutdown, ... (text varies upon the compressors actual condition)
(4) Menu
Typical Main screen (4 value lines), fixed speed compressors
