5 6
7 8
9 10
11 12
13 14
15
Reference Designation
1 Warning: Always read the manual, switch off the voltage, depressurise compressor and
lock out/ tag out before repairing.
2 Keep the doors closed during operation
3 Switch off the voltage before removing protecting cover inside electric cubicle
4 Warning, voltage
5 Automatic condensate drain
6 Stop the compressor before cleaning the coolers
7 Lightly oil the gasket of the oil filter, screw it on and tighten by hand (approx. half a turn)
Instruction book
2920 7190 02 71
