Reference Designation
8 Before connecting the compressor electrically, consult the Instruction book for the motor
rotation direction
9 Compressor remains pressurized for 180 seconds after switching off the voltage
10 Torques for steel (Fe) or brass (CuZn) bolts
11 Switch off the voltage and wait at least 6 minutes before removing the screen
12 Oil outlet
13 Cooling water inlet
14 Cooling water outlet
15 Automatic Restart After Voltage Failure (ARAVF)
Instruction book
72 2920 7190 02
