Section III - Installation
Alarm Connection
To enable the alarm facility, it is
recommended that a suitable cable is
brought into the controller via the rear
panel with a grommet. An external power
source is required.
Connect the switching pole of an
externally powered alarm device to
terminals 1 and 2 of the alarm DIN
connector.
1.
With power removed from the
dryer and the alarm lead wired as
described in step 1, remove the cover
from the DIN connection marked
‘Alarm’ and connect the wired DIN
connector ensuring the seal and
screw are fitted.
AlArm relAy rAting 3 Amp mAx 28 vdc
A
lArm connection
type
HirscHmAnn gds 207
industriAl stAndArd
din connector or
equivAlent
2.
Quincy Compressor-QMOD 13
