Section V - Servicing
Removing and Replacing the Front
Panel
dryer WitH front fAsciA pAnel fitted.
remove retAining screW to remove front fAsciA pAnel.
remove front fAsciA pAnel By tilting outWArds And
doWnWArds.
dryer WitH front fAsciA pAnel removed.
refit front fAsciA pAnel By inserting tongue into
groove And pusHing upWArds And inWArds.
replAce retAining screW.
