Section V - Servicing
Purge Plug Removal
remove front pAnel of dryer As descriBed on pAge 22
And locAte purge plug in tHe upper vAlve BlocK.
remove purge plug fixing screW from upper vAlve BlocK.
remove purge plug from port in upper vAlve BlocK.
cleAn orifice in purge plug WitH WArm soApy WAter. do
not use sHArp implements or tools.
tHorougHly dry tHe purge plug And ensure tHAt tHe
o-rings Are in plAce And in good condition. pusH tHe
purge plug into tHe port in tHe vAlve BlocK.
replAce And tigHten purge plug fixing screW in tHe
upper vAlve BlocK.
Cleaning the Silencer
disconnect & remove silencer from vAlve BlocK.
tHorougHly cleAn tHe silencer in WArm soApy WAter.
do not use sHArp instruments or tools. cleAn tHreAds
on silencer.
NOTICE!
Ensure silencer is thoroughly clean and
dry before re-installing.
