Section V - Servicing
Replacing the Diaphragm
remove front pAnel of dryer As descriBed on pAge 22
And locAte upper And loWer Bonnets.
loWer Bonnets.
remove tHe Bonnets By removing four fixing screWs.
tHe silencer cAn Be removed for mAintenAnce if
necessAry.
sepArAte tHe Bonnets from tHe vAlve BlocK.
disconnect tuBing from fitting on Bonnet.
locAte And remove tHe diApHrAgm AssemBly to Be
cHAnged.
diApHrAgm And Bonnet components. replAce All
diApHrAgms And Bonnets And reAssemBle dryer.
