Section IV - Operating Procedures
NOTICE!
For point of use dryers or constant
running dryers utilizing dewpoint
monitoring, the dry receiver system
should be activated regardless of
installation.
By switching to ‘Dry Receiver System’ the
energy management facility will operate
after a 15 seconds delay.
For wet receiver applications, select the
‘Wet Receiver System’ box. With this
system active, the high and low pressure
set points of the compressor, the internal
volume of the receiver and the flow rate
of the dryer must be input to calculate the
necessary delay.
The purpose of the delay is to prevent
dryer saturation when using a large
receiver with a large range of set pressures.
Once the application conditions have been
input, click ‘OK’ to return the screen to the
main application software.
Click ‘Program SFD’ to save the defined
settings.
Quincy Compressor-QMOD 19
