Quincy Compressor QMOD00008 - Pressure and Temperature Correction Factors

Appendix A - Technical Data
oPerAting
P
reSSure
BArg (PSig)
4 (58) 5 (72) 6 (87)
7
(100)
8
(116)
9
(130)
10
(145)
11
(160)
12
(174)
13
(189)
14
(203)
15
(218)
16
(232)
P
reSSure
c
orrection
F
Actor (PcF)
0.62 0.75 0.87 1 1.12 1.25 1.37 1.5 1.62 1.75 1.87 2.0 2.12
Always use the pressure correction factor (PCF) closest to the actual inlet pressure
condition.
temPerAture
°c (°F)
20
(68)
25
(77)
30
(86)
35
(95)
40
(104)
45
(113)
50
(122)
t
emPerAture
c
orrection
F
Actor (tcF)
1.07 1.06 1.04 1.00 0.93 0.78 0.64
DewPoint °c
(°F)
-40
(-40)
-70
(-100)
DewPoint
c
orrection
F
Actor ( DcF )
1 0.7
SPeciFicAtionS
stAndArd pressure deWpoint
-40°c (-40°f)
-70°c (-100°f) W/ApplicAtion of floW correction fActor
minimum worKing PreSSure
4 BArg (58 psig)
mAximum worKing PreSSure
16 BArg (232 psig)
electricAl controlS
12 vdc to 24 vdc/100 vAc to 240 vAc
minimum inlet temPerAture
1.5°c (35°f)
mAximum inlet temPerAture
50°c (112°f)
minimum AmBient temPerAture
5°c (41°f)
Quincy Compressor-QMOD 29
