Instruction Reference Manual 7
3. Document Conventions
Instruction Table Key
• Opcode: A hexidecimal representation of the value that the mnemonic instruction represents.
• Instruction: The mnemonic syntax of the instruction.
• Clocks: The number of clock cycles it takes to complete this instruction. The numbers in parenthesis
are a breakdown of the total clocks. The number of clocks instructions take follows a general patern.
There are several Rabbit instructions that do not adhere to this pattern. Some instructions take more
clocks and some have been enhanced to take fewer clocks.
Table 1: Typical Clocks Breakdown
• Operation: A symbolic representation of the operation performed.
Process Clocks
Each byte of the opcode. 2
Each data byte read. 2
Write to memory or external IO. 3
Write to internal IO. 2
Internal operation or computation. 1
