74 Rabbit 2000/3000 Microprocessor
Description
• LD HL,(mn): Loads L with the data whose address is mn and loads the H with the data
whose address is mn plus 1.
• LD HL,(HL+d): Loads L with the data whose address is the data in HL plus a displacement
d. Then loads H with the data whose address is the data in HL plus a displacement d plus 1.
• LD HL,(IX+d): Loads L with the data whose address is the data in IX plus a displacement
d. Then loads H with the data whose address is the data in IX plus a displacement d plus 1.
• LD HL,(IY+d): Loads L with the data whose address is the data in IY plus a displacement
d. Then loads H with the data whose address is the data in IY plus a displacement d plus 1.
LD HL,(mn)
LD HL,(HL+d)
LD HL,(IX+d)
LD HL,(IY+d)
Opcode Instruction Clocks Operation
2A mn LD HL,(mn) 11 (2,2,2,1,2,2) L=(mn);H=(mn +1)
DD E4 d LD HL,(HL+d) 11 (2,2,2,1,2,2) L = (HL + d); H = (HL + d +1)
E4 d LD HL,(IX+d) 9 (2,2,1,2,2) L = (IX + d); H = (IX + d +1)
FD E4 d LD HL,(IY+d) 11 (2,2,2,1,2,2) L = (IY + d); H = (IY + d +1)
Flags ALTD I/O
S Z L/V C F R SP S D
- - - - • •
