Instruction Reference Manual 93
Description
This instruction is similar to the JP mn instruction in that it transfers program execution to the memory loca-
tion specified by the 16-bit address, mn. LJP is special in that it allows a jump to be made to a computed
address in XMEM. Note that the value of XPC and consequently the address space defined by the XPC is
dynamically changed with the LJP instructions.
The instruction loads the XPC with the 8-bit constant x. Then loads PC with the 16-bit constant mn,which
must be in the range E000–FFFF.
This instruction recognizes labels when used in the Dynamic C assembler.
LJP x,mn
Opcode Instruction Clocks Operation
C7 nmx LJP x,mn 10 (2,2,2,2,2) XPC = x;PC=mn
Flags ALTD I/O
S Z L/V C F R SP S D
- - - -
