Rabbit 2000 - LD IY,(Mn)

80 Rabbit 2000/3000 Microprocessor
Description
Loads the low order byte of IY with the data at the address mn and loads the high order byte of IY with the
data at the address mn+1.
LD IY,(mn)
Opcode Instruction Clocks Operation
FD 2A nm LD IY,(mn) 13* IY
(low)
=(mn); IY
(high)
=(mn +1)
*Clocking: 13 (2,2,2,2,1,2,2)
Flags ALTD I/O
S Z L/V C F R SP S D
- - - - •
