Rabbit 2000 - SET B,(HL)

Instruction Reference Manual 135
Description
Sets bit b (anyofthebits0,1,2,3,4,5,6,or7)ofthebytewhoseaddressis
• the data in HL, or
• the sum of the data in IX and a displacement d,or
• the sum of the data in IY and a displacement d.
SET b,(HL)
SET b,(IX+d)
SET b,(IY+d)
Opcode Instruction Clocks Operation
CB C6
CB CE
CB D6
CB DE
CB E6
CB EE
CB F6
CB FE
SET b,(HL)
SET bit 0,(HL)
SET bit 1,(HL)
SET bit 2,(HL)
SET bit 3,(HL)
SET bit 4,(HL)
SET bit 5,(HL)
SET bit 6,(HL)
SET bit 7,(HL)
10*
10*
10*
10*
10*
10*
10*
10*
10*
(HL) = (HL) | bit
(HL) = (HL) | bit 0
(HL) = (HL) | bit 1
(HL) = (HL) | bit 2
(HL) = (HL) | bit 3
(HL) = (HL) | bit 4
(HL) = (HL) | bit 5
(HL) = (HL) | bit 6
(HL) = (HL) | bit 7
DD CB d C6
DD CB d CE
DD CB d D6
DD CB d DE
DD CB d E6
DD CB d EE
DD CB d F6
DD CB d FE
SET b,(IX+d)
SET bit 0,(IX+d)
SET bit 1,(IX+d)
SET bit 2,(IX+d)
SET bit 3,(IX+d)
SET bit 4,(IX+d)
SET bit 5,(IX+d)
SET bit 6,(IX+d)
SET bit 7,(IX+d)
13**
13**
13**
13**
13**
13**
13**
13**
13**
(IX + d)=(IX+d)|bit
(IX + d)=(IX+d)|bit0
(IX + d)=(IX+d)|bit1
(IX + d)=(IX+d)|bit2
(IX + d)=(IX+d)|bit3
(IX + d)=(IX+d)|bit4
(IX + d)=(IX+d)|bit5
(IX + d)=(IX+d)|bit6
(IX + d)=(IX+d)|bit7
FD CB d C6
FD CB d CE
FD CB d D6
FD CB d DE
FD CB d E6
FD CB d EE
FD CB d F6
FD CB d FE
SET b,(IY+d)
SET bit 0,(IY+d)
SET bit 1,(IY+d)
SET bit 2,(IY+d)
SET bit 3,(IY+d)
SET bit 4,(IY+d)
SET bit 5,(IY+d)
SET bit 6,(IY+d)
SET bit 7,(IY+d)
13**
13**
13**
13**
13**
13**
13**
13**
13**
(IY + d)=(IY+d)|bit
(IY + d)=(IY+d)|bit0
(IY + d)=(IY+d)|bit1
(IY + d)=(IY+d)|bit2
(IY + d)=(IY+d)|bit3
(IY + d)=(IY+d)|bit4
(IY + d)=(IY+d)|bit5
(IY + d)=(IY+d)|bit6
(IY + d)=(IY+d)|bit7
Clocking: *10 (2,2,1,2,3) **13 (2,2,2,2,2,3)
Flags ALTD I/O
S Z L/V C F R SP S D
- - - - • •
