Rabbit 2000 - LD R,(HL)

82 Rabbit 2000/3000 Microprocessor
Description
Loads r (any of the registers A, B, C, D, E, H, or L) with the data whose address is:
• the data in HL, or
• the sum of the data in IX and a displacement d,or
• the sum of the data in IY and a displacement d.
LD r,(HL)
LD r,(IX+d)
LD r,(IY+d)
Opcode Instruction Clocks Operation
——
7E
46
4E
56
5E
66
6E
LD r,(HL)
LD A,(HL)
LD B,(HL)
LD C,(HL)
LD D,(HL)
LD E,(HL)
LD H,(HL)
LD L,(HL)
5 (2,1,2)
5 (2,1,2)
5 (2,1,2)
5 (2,1,2)
5 (2,1,2)
5 (2,1,2)
5 (2,1,2)
5 (2,1,2)
r = (HL)
A = (HL)
B = (HL)
C = (HL)
D = (HL)
E = (HL)
H = (HL)
L = (HL)
——
DD 7E d
DD 46 d
DD 4E d
DD 56 d
DD 5E d
DD 66 d
DD 6E d
LD r,(IX+d)
LD A,(IX+d)
LD B,(IX+d)
LD C,(IX+d)
LD D,(IX+d)
LD E,(IX+d)
LD H,(IX+d)
LD L,(IX+d)
9 (2,2,2,1,2)
9 (2,2,2,1,2)
9 (2,2,2,1,2)
9 (2,2,2,1,2)
9 (2,2,2,1,2)
9 (2,2,2,1,2)
9 (2,2,2,1,2)
9 (2,2,2,1,2)
r = (IX + d)
A = (IX + d)
B = (IX + d)
C = (IX + d)
D = (IX + d)
E = (IX + d)
H = (IX + d)
L = (IX + d)
——
FD 7E d
FD 46 d
FD 4E d
FD 56 d
FD 5E d
FD 66 d
FD 6E d
LD r,(IY+d)
LD A,(IY+d)
LD B,(IY+d)
LD C,(IY+d)
LD D,(IY+d)
LD E,(IY+d)
LD H,(IY+d)
LD L,(IY+d)
9 (2,2,2,1,2)
9 (2,2,2,1,2)
9 (2,2,2,1,2)
9 (2,2,2,1,2)
9 (2,2,2,1,2)
9 (2,2,2,1,2)
9 (2,2,2,1,2)
9 (2,2,2,1,2)
r = (IY + d)
A = (IY + d)
B = (IY + d)
C = (IY + d)
D = (IY + d)
E = (IY + d)
H = (IY + d)
L = (IY + d)
Flags ALTD I/O
S Z L/V C F R SP S D
- - - - • •
