Rabbit 2000 - Page 87

Instruction Reference Manual 83
Description
Loads r (any of the registers A, B, C, D, E, H, or L) with the 8-bit constant n.
LD r,n
Opcode Instruction Clocks Operation
——
3E n
06 n
0E n
16 n
1E n
26 n
2E n
LD r,n
LD A,n
LD B,n
LD C,n
LD D,n
LD E,n
LD H,n
LD L,n
4 (2,2)
4 (2,2)
4 (2,2)
4 (2,2)
4 (2,2)
4 (2,2)
4 (2,2)
4 (2,2)
r = n
A=n
B=n
C=n
D=n
E=n
H=n
L=n
Flags ALTD I/O
S Z L/V C F R SP S D
- - - - •
