Rabbit 2000 - RES B,(HL)

110 Rabbit 2000/3000 Microprocessor
Description
Resets bit b (anyofthebits0,1,2,3,4,5,6,or7)ofthedatawhoseaddressis:
• heldinHL, or
• the sum of the data in IX and a displacement d,or
• the sum of the data in IY and a displacement d.
The bit is reset by performing a logical AND between the selected bit and its complement.
RES b,(HL)
RES b,(IX+d)
RES b,(IY+d)
Opcode Instruction Clocks Operation
——
CB 86
CB 8E
CB 96
CB 9E
CB A6
CB AE
CB B6
CB BE
RES b,(HL)
RES bit 0,(HL)
RES bit 1,(HL)
RES bit 2,(HL)
RES bit 3,(HL)
RES bit 4,(HL)
RES bit 5,(HL)
RES bit 6,(HL)
RES bit 7,(HL)
10*
10*
10*
10*
10*
10*
10*
10*
10*
(HL) = (HL) & ~bit b
(HL) = (HL) & ~bit 0
(HL) = (HL) & ~bit 1
(HL) = (HL) & ~bit 2
(HL) = (HL) & ~bit 3
(HL) = (HL) & ~bit 4
(HL) = (HL) & ~bit 5
(HL) = (HL) & ~bit 6
(HL) = (HL) & ~bit 7
——
DD CB d 86
DD CB d 8E
DD CB d 96
DD CB d 9E
DD CB d A6
DD CB d AE
DD CB d B6
DD CB d BE
RES b,(IX+d)
RES bit 0,(IX+d)
RES bit 1,(IX+d)
RES bit 2,(IX+d)
RES bit 3,(IX+d)
RES bit 4,(IX+d)
RES bit 5,(IX+d)
RES bit 6,(IX+d)
RES bit 7,(IX+d)
13**
13**
13**
13**
13**
13**
13**
13**
13**
(IX + d)=(IX+d)&~bit
(IX + d) = (IX + d)&~bit0
(IX + d) = (IX + d)&~bit1
(IX + d) = (IX + d)&~bit2
(IX + d) = (IX + d)&~bit3
(IX + d) = (IX + d)&~bit4
(IX + d) = (IX + d)&~bit5
(IX + d) = (IX + d)&~bit6
(IX + d) = (IX + d)&~bit7
——
FD CB d 86
FD CB d 8E
FD CB d 96
FD CB d 9E
FD CB d A6
FD CB d AE
FD CB d B6
FD CB d BE
RES b,(IY+d)
RES bit 0,(IY+d)
RES bit 1,(IY+d)
RES bit 2,(IY+d)
RES bit 3,(IY+d)
RES bit 4,(IY+d)
RES bit 5,(IY+d)
RES bit 6,(IY+d)
RES bit 7,(IY+d)
13**
13**
13**
13**
13**
13**
13**
13**
13**
(IY + d)=(IY+d)&~bit
(IY + d) = (IY + d)&~bit0
(IY + d) = (IY + d)&~bit1
(IY + d) = (IY + d)&~bit2
(IY + d) = (IY + d)&~bit3
(IY + d) = (IY + d)&~bit4
(IY + d) = (IY + d)&~bit5
(IY + d) = (IY + d)&~bit6
(IY + d) = (IY + d)&~bit7
Clocking: *10 (2,2,1,2,3) **13 (2,2,2,2,2,3)
Flags ALTD I/O
S Z L/V C F R SP S D
- - - - •
