Description
Performs an exclusive OR operation between the byte in A and the 8-bit constant n. The corresponding bits of
each byte are compared (i.e., bit 0 of both bytes are compared, the bit 1 of both bytes are compared, etc.). The
associated bit in the result byte is set if and only if one of the two compared bits is set. The result is stored in
A.
XOR n
Opcode Instruction Clocks Operation
EE n XOR n 4 (2,2) A=[A&~n] | [~A & n]
Flags ALTD I/O
S Z L/V C F R SP S D
• • L0 • •
