Description
ThedatainAissummedwiththeCflagandwiththedatain r (any of the registers A, B, C, D, E, H, or L).
TheresultisstoredinA.
ADC A,r
Opcode Instruction Clocks Operation
—— ADC A,r 2 A=A+r +CF
8F ADC A,A 2 A=A+A+CF
88 ADC A,B 2 A=A+B+CF
89 ADC A,C 2 A=A+C+CF
8A ADC A,D 2 A=A+D+CF
8B ADC A,E 2 A=A+E+CF
8C ADC A,H 2 A=A+H+CF
8D ADC A,L 2 A=A+L+CF
Flags ALTD I/O
S Z L/V C F R SP S D
• • V • • •
