32 Rabbit 2000/3000 Microprocessor
Description
This instruction is used to call a subroutine. First the data in PC is pushed onto the stack. The high-order byte
of PC is pushed first, then the low-order byte. PC is then loaded with mn,16-bit address of the first instruction
of the subroutine. SP is updated to reflect the two bytes pushed onto the stack.
The Dynamic C assembler recognizes CALL label,wheremn is coded as a label.
CALL mn
Opcode Instruction Clocks Operation
CD nm CALL mn 12 (2,2,2,3,3) (SP - 1) = PC
(high)
;
(SP - 2) = PC
(low)
;
PC = mn; SP = SP - 2
Flags ALTD I/O
S Z L/V C F R SP S D
- - - -
