Description
The data in A is inverted (one’s complement).
Example
If the data in A is 1100 0101, after the instruction CPL A will contain 0011 1010.
CPL
Opcode Instruction Clocks Operation
2F CPL 2 A=~A
Flags ALTD I/O
S Z L/V C F R SP S D
- - - - •
