4
Navigate between monitoring groups values by using the up and
down buttons.
5
Press OK to see monitoring value.
6
Press Back/Reset to return to the main display.
5.3.3 Parameter menu
In the parameter menu, you can set the values for the parameters. Parameters are shown according to password
level.
Code Parameter name Range Default Unit Description Password
level
P1.1 Password 1-65535 0 - Startup = 47
Engineering = 129
0
Accessing the parameter menu
1
Press back/reset button until the display momentarily empties and
the main selection arrow blinks.
2
Press the down arrow button until the display indicator is pointing
towards the PAR menu.
3
Press OK.
4
Navigate between parameter groups by using the up and down
buttons.
