8 TECHNICAL DATA
Mains connection
Supply voltage U
in
380 - 480V, -10%...+10% 3-phase
Supply voltage frequency 45…66 Hz
Connection to mains Once per minute or less (normal case)
Motor connection Output voltage 0 — U
in
Nominal output current 003: I
N
5.6A (max 8.4A), 006: I
N
5.6A (max 8.4A), 012: I
N
12A (max 18A)
Continuous output current
Rated current I
n
at ambient temperature max +50
C, overload 1.5 x I
N
max
(1min/10min)
Starting current 2 x I
N
2 sec every 20 sec
Output frequency 0…250 Hz (limited options)
Digital inputs Control voltage 42 – 240 V
ac
, current consumption 14 - 20 mA
Control features Control method
Frequency Control U/f
Open Loop Sensorless Vector Control
Switching frequency 3,6 kHz
Field weakening point Adjustable with parameter
Acceleration time 0…20s (0,1s steps)
Deceleration time 0…20s (0,1s steps)
Ambient conditions Ambient operating temperature –10°C (no frost)…+50° C (outside the cubicle + 40˚C)
Storage temperature –40°C…+70°C
Relative humidity 0…95% RH, non-condensing, non-corrosive, no dripping water
Air quality:
- Chemical vapors
- Mechanical particles
IEC 721-3-3, unit in operation, class 3C2
IEC 721-3-3, unit in operation, class 3S2
Altitude
100% load capacity (no derating) up to 1000m. 1% derating for each 100m
above 1000m; max. 2000m
Vibration:
EN50178/EN60068-2-6
5...150 Hz
Displacement amplitude 1 (peak) mm at 5...15.8 Hz
Max acceleration amplitude 1 G at 15.8...150 Hz
Shock
EN50178, IEC 68-2-27
UPS Drop Test (for applicable UPS weights)
Storage and shipping: max 15 G, 11 ms (in package)
Enclosure class IP20
Weight 003 model: 0.9 kg, 006 model: 1.2 kg, 012 model: 1.7 kg
Safety
61800-5-1 (2007), EN60204-1 (2009), CE, UL, cUL, FI, GOST R, IEC (see
the unit’s main sticker for more detailed approvals), RoHS
Protections Over voltage protection 875V
DC
trip level
Under voltage protection 333V
DC
trip level
Earth-fault protection
Earth fault is tested before every start. In case of earth fault in motor or
motor cable, only the frequency converter is protected.
Unit over temperature Yes
Motor stall Yes
Overcurrent protection Trip limit 4,0*I
N
instantaneously
Motor overtemperature supervision Yes
