R&M ControlMaster NXT - Page 44

Table 5. Maximum and minimum frequency 80 Hz
CMX 022 Minimum
frequency (Hz) To
P1.2
Maximum Frequency
(Hz) To P1.3
Switch S1
-1 -2 -3 -4
0 0 0 0 22 77
0 0 0 1 14 42
0 0 1 0 18 50
0 0 1 1 10 40
0 1 0 0 30 62
0 1 0 1 12 44
0 1 1 0 16 46
0 1 1 1 20 48
1 0 0 0 40 80
1 0 0 1 24 53
1 0 1 0 26 56
1 0 1 1 28 59
1 1 0 0 32 65
1 1 0 1 34 68
1 1 1 0 36 71
1 1 1 1 38 74
Table 6. Maximum and minimum frequency 50/60 Hz
CMX 022 Minimum frequency
(Hz) To P1.2
Maximum Frequency
(Hz) To P1.3
Switch S1
-1 -2 -3 -4
0 0 0 0 15 50
0 0 0 1 7 25
0 0 1 0 12 31
0 0 1 1 5 27
0 1 0 0 16 40
0 1 0 1 6 29
