USER MANUAL – RCS
7.10 Replacing the batteries of the indicator (before 2013)
The indicator is equipped with 4 AA batteries.
Replace the batteries as soon as the
LO-BA indication will blink.
As the LO-BA indication starts to flash
while printing (option), replace the
batteries.
Remove the M6 Allen screw with an
Allan key and open the housing of the
indicator.
Insert the new batteries in the housing.
Place the batteries correctly. Check the
polarity!
Remove the top side of the housing and
remove the batteries.
Fit the housing of the indicator and
tighten the M6 Allen screws with an
Allen wrench.
