USER MANUAL – RCS
12. Options
These options can not be added once the system is mounted and can only be bought with a
new system.
12.1 Power supply by the trucks battery
The indicator is installed in the cabin of the forklift truck.
Optionally, the power supply of the indicator
can be connected to the battery of the forklift truck. The most common voltages for forklift trucks are
12, 24, 48 or 80.
In cases where the battery voltage is higher then 12 Vdc, the system requires a DC-DC voltage
converter with an output voltage of 12 Vdc and possibly a filter.
In addition, the power cable of the indicator with a floating fuse holder with 3 .15A safety fuse.
12.1.1 Guidelines to connect the power supply
• Make sure that the fuse is as close to the power source as possible.
• The fuse must be mounted safely and in an accessible location.
• On electric forklifts:
Connect the power supply to the battery as close as possible, do not mount it directly on the
battery or in front of a fuse.
• On petrol, diesel or propane forklifts:
Connect the power supply as close to the battery as possible, and avoid the use of existing
wiring.
12.1.2 Guidelines for installation
Please note: always turn off the power supply before installation !
The installer should be familiar with the brands and models of equipment on which this converter is
installed. The installer should also be trained and have experience in electrical systems of forklifts.
Follow the guidelines and the installation procedures as well as the guidelines of the forklift
manufacturer to guarantee a safe an reliable installation.
• Make sure that the power supply is connected safely;
• Make sure the mounting surface is firm;
• Make sure the mounting surface can dissipate the heat from the power supply good;
• Make sure that the fuse is close to the battery of the forklift and matched with related weighing
equipment;
• Keep the cables as short as possible, fixate it at least every 45 cm. (18 inch).
Make sure you become familiar with the requirements of the lift truck manufacturer and make sure you
have the right qualifications to perform the installation of the power supply.
The converter must be installed in a suitable location.
See installation steps below:
Step 1 . Plan the installation and get the hardware
Stap 2 . Install the indicator
Stap 3 . Install the converter ( if necessary )
Stap 4 . Install the further options such as printers, mobile computer and connections
Use only an approved and properly tuned power supply suitable for the country of operation. Use of
alternative power supplies will void the system's warranty and can be dangerous.
WARNING! Only qualified personnel should perform an installation to a forklift. Improper installation
can injure the operator or cause damage to the system, inverter, and/or the other options!
