CHAPTER 6
46 Hawkeye® 2 Installation Manual for AGCO RoGator C-Series (RG900, RG1100, RG1300)
FIGURE 4. System Diagram (Page 1)
RCM
063-0173-956
CABLE, ECU,
ROGATOR C,
HAWKEYE 2
115-2005-017
CABLE, BULKHEAD,
ROGATOR C,
HAWKEYE 2
115-2005-018
CABLE, ECU BOX TO
RCM, HAWKEYE 2
115-2005-019
60
AMP
CIRCUIT
BREAKER
NCV
POWER
FUSES &
RELAYS
TO BATT
GROUND
ROGATOR
C PDM
TO AGCO
HARNESS
LEFT/RIGHT
NCV CANBUS
DIAGNOSTICS
ROGATOR C ECU
CABINET
* OPTIONAL:
SECTION CONTROL
REMOTE
P/N: 063-0174-001
TO LEFT BOOM TO RIGHT BOOM
