Raven AGCO RoGator Hawkeye C Series User Manual

Chassis Cable Installation: System Diagrams 47
CHASSIS CABLE INSTALLATION
FIGURE 5. System Diagram (Page 2)
BOOM CABLES AND KITS AGCO ROGATOR C
ITEM
NO.
DESCRIPTION
90' BOOM
15" SPACING
90' BOOM
20" SPACING
100' BOOM
15" SPACING
100' BOOM
19" SPACING
100' BOOM
20" SPACING
120' BOOM
10" SPACING
120' BOOM
15" SPACING
120' BOOM
19" SPACING
120' BOOM
20" SPACING
132' BOOM
19" SPACING
132' BOOM
20" SPACING
1
CABLE, INNER
(LEFT)
115-2005-187 115-2005-123 115-2005-187 115-2005-179 115-2005-123 115-2005-162 115-2005-183 115-2005-151 115-2005-002 115-2005-151 115-2005-159
2
CABLE, INNER
(RIGHT)
115-2005-188 115-2005-123 115-2005-188 115-2005-180 115-2005-123 115-2005-163 115-2005-184 115-2005-152 115-2005-002 115-2005-152 115-2005-159
3
CABLE, MID
(QTY 2)
115-2005-189 115-2005-124 115-2005-189 115-2005-181 115-2005-124 115-2005-164 115-2005-185 115-2005-177 115-2005-003 115-2005-153 115-2005-160
4
CABLE, OUTER
(QTY 2)
115-2005-350 115-2005-205 115-2005-190 115-2005-182 115-2005-125 115-2005-165 115-2005-186 115-2005-178 115-2005-004 115-2005-154 115-2005-161
5
ARAG/HYPRO NCV
WILGER NCV
063-2005-002 063-2005-003
(QTY: 73)
063-2005-002
063-2005-003
(QTY: 54)
063-2005-002
063-2005-003
(QTY: 81)
063-2005-002
063-2005-003
(QTY: 63)
063-2005-002
063-2005-003
(QTY: 60)
063-2005-002
(QTY: 143)
063-2005-002
063-2005-003
(QTY: 97)
063-2005-002 063-2005-003
(QTY: 72)
063-2005-002 063-2005-003
(QTY: 72)
063-2005-002 063-2005-003
(QTY: 85)
063-2005-002
03-2005-003
(QTY: 80)
N/A KITS
117-2005-114
(WILGER)
117-2005-117
(ARAG/HYPRO)
117-2005-103
(WILGER)
117-2005-107
(ARAG/HYPRO)
117-2005-113
(WILGER)
117-2005-116
(ARAG/HYPRO)
117-2005-110
(ARAG/HYPRO)
117-2005-102
(WILGER)
117-2005-106
(ARAG/HYPRO)
117-2005-118
(ARAG/HYPRO)
117-2005-112
(WILGER)
117-2005-115
(ARAG/HYPRO)
117-2005-109
(ARAG/HYPRO)
117-2005-101
(WILGER)
117-2005-105
(ARAG/HYPRO)
117-2005-108
(ARAG/HYPRO)
117-2005-100
(WILGER)
117-2005-104
(ARAG/HYPRO)
ECO #
RELEASED
DATE
REV.
DRAWING NO.
9/14/21
37951
B 054-2005-007
8/10/22 42754 C 054-2005-007
CABLE, INNER, LEFT CABLE, MID CABLE, OUTERCABLE, INNER, RIGHTCABLE, MIDCABLE, OUTER
NOTES:
1. NOT ALL CONNECTIONS SHOWN.
2. ALL KITS INCLUDE A SYSTEM SERVICE KIT, O-RINGS, AND NECESSARY ECU MOUNTING BRACKET AND HARDWARE
TO COMPLETE INSTALLATION.
3. A 1.5" HOLE MUST BE DRILLED IN THE REAR OF THE ECU CABINET WITH A HOLE SAW (NOT PROVIDED) FOR A
CABLE BULKHEAD CONNECTION.
4. WILGER KITS INCLUDE WILGER DUAL OUTLET NOZZLE BODIES AND PROSTOP-E TO WILGER THREAD ADAPTERS TO
USE HAWKEYE 2 NCV'S TO CONTROL ONE OUTLET AND PROSTOP-E VALVES (NOT INCLUDED) TO CONTROL THE
SECOND OUTLET OF EACH NOZZLE BODY.
NCV, HAWKEYE 2, HYPRO/ARAG: 063-2005-002 NCV, HAWKEYE 2, WILGER: 063-2005-003
TO ECU CABLE
SHEET 2 OF 2
